Core Fin Types

ML is a high efficiency multi-louvered plate-fin core, with a staggered tube layout. The product is suitable to a wide variety of industrial applications, and is available from 2 row (38mm) to 8 row (143mm).

Features include:

• Industrial construction with high thermal efficiency
• Split louvre - high strength, retains shape, low external fouling characteristic
• Deep hem
• Options - Ultra-Fused joints and SC

A high strength industrial plate-fin core, incorporating staggered tube layout and ribbed fin design. This core offers exceptional thermal performance for a non-louvered fin design. Available from 2 row (38mm) to 8 row (143mm).

Features include:

• Heavy duty industrial construction
• Ribbed fin - high strength, suited to high external fouling applications (easily cleaned)
• Deep hem
• Options - Ultra-Fused joints and SC

This multi-louvered serpentine-fin (CT) core construction offers high thermal performance and excellent mechanical properties. Available from 2 row (36mm) to 4 row (76mm).

Features include:

• Heavy duty serpentine fin
• Split louvre - high strength, retains shape
• Suited to smooth and dimpled tube
• Options - Ultra-Fused joints

Suited to applications exposed to high levels of external fouling. This multi-louvered inline provides a practical balance between thermal efficiency with low fouling characteristics. Available from 2 row (43mm) to 6 row (132mm).

Features include:

• Industrial construction
• In-line tube layout - low fouling characteristic
• Split louvre - high strength, retains shape, low external fouling characteristic
• Deep hem
• Options - Ultra-Fused joints and SC


The CA-Core surface is a copper fin/brass tube heat transfer matrix specifically designed for industrial charge air-to-air cooling. Available from 2 row (49mm) to 12 row (303mm).

Features include:

• Heavy duty Industrial construction
• Purpose designed for charge air-to-air cooling
• In-line tube layout - low fouling characteristic
• Deep hem
• Options - Ultra-Fused joints and SC
